Features:

This Lock is the most perfect choice of Chinese high-star hotels which makes use of the most advanced sciences of electronics, forging, computer, mechanics, material, latest esthetics. It embodies Chinese spirit and philosophy: the golden mean.
  1、The drilled hole is the smallest in the world when installing the lock. The paticular patent design lessens the breakage to the door ensuring that the hotel can change the type of locks in future.
  2、We deal with the cuputer board by  degradation, prevent magnet and dust, subjoining performances, flying probe, computer test shelf for 180 hours in the Germany stove. Then it will go through deep oxidation and tin printed management. The perfomance is very stable. All the components are imported directly abroad. The SCM uses software instuments to ensure not tampered, system halted. Long stable work.
  3、Double electrical machine, 3-linkage, 4 absolute master/slave controlled circuits, 5 hierarchical management, 5 interface functions, big volume records of door opening, kinds of report forms of records, etc. will satisfy any big or small hotels, villas, housing estates, the needs of professional flat adminstrantion and function upgrading. It fits famous software home and abroad.
  4、ALL the products are forged by Luoyang Copper or Switzerland horniness steel once. It accords with ISO7816 and the USA standard. Design for avoid sawing, stiring,insertion and pry is hided in the lock. All the hardwares pass through management of anti-salt, anti-alkali, anti-acid.
  5、The surfance adopts plating technics of car vacuum nanometer ion multilayer. It is very beautiful and corrosion resistant. It can insure that the plated layer won't fall off in 7 years. The gilt parts won't fade for 8 years. And the material and thickness of the layer can be customized.
  6、Colors such as rose color, champane gold, ruby red, silver grey, cambridge blue can be chosen. Uphold hotel style and display its dignity.vent the external stress from ruining the internal structure. The working life is long.

Technical Specification:

1、Card Type: ID, TEMIC, MF1;
2、Make use of the inductive technology of electromagnetic wave; The induction is more sensitive. Inductive distance ≤5cm;
3、Power Supply: DC 6V , 4 pieces of No.5 alkaline batteries. It can be used for more than one year in normal state.
4、The main chip of circuit board is the USA Texas Instrument TI Chip. Power Consumption: satic current ≤15 μA, card reading current ≤20 mA, lock opening current: about 300 mA (last for 0.3s), Work Settings:temprature:-20℃～+70℃, Humidity ≤95% RH;
5、Lack of Voltage Indication: When the voltage is less than 4.8V, there will be a 3 sound and the red LED will light. Furthermore,the lock can still be opened for more than 50 times.
6、Application: hotels, parking lot,residence community, office entrance guard and so on.
7、Specialities: output guard, water proof and moisture proof,tamper-proof management. Anti-static electricity >15,000 V, it ensures information inside the lock not missing under the interference of strong static electricity.
8、System Configurations: a computer (provided for yourself), a suit of software system of making cards, a card-maker, cards, locks.

Note:

The software of the system can be connected to the hotel administration system, realising One-Card-Pass function. The operation is easy.

Our products are detected by relevant departments such as Ministry of Public Security and get European Union CE attestation.
