1.    Triplex (Recording, Playback, Network)

2.    Multiple Screen division (1,4,8)

3.    H.264 Hardware compression (High Quality video)

4.    Easy to Use and convenient GUI

5.    Embedded Linux Operating System

6.    Fast operation by mouse and remote controller

7.    Network: TCP/IP, PPPOE, DDNS, Email and MSN

8.    Event Recording: Motion detection and sensor

9.    Backup by U-Disk, Network

10. HDD with SATA interface and capacity over 1TB

11. Remote monitor, Remote playback by web browser,3G mobile for monitor

12. Compression: H.264

13. Video Format: NTSC/PAL

14. Video Input: 8 CH

15. Video Output: 2 CH

16. Audio Input: 4 CH

17. Audio Output: 1 CH

18. Recording Resolution: D1,Half D1,CIF

19. Display Speed: 240fps(NTSC),200fps(PAL)

20. Recording Speed: 240fps(NTSC),200fps(PAL) for CIF

21. Storage Media: 1(SATA)HDD

22. Backup Media: U-Disk/Network

23. Sensor Input: 8 CH

24. Alarm Output: 1 CH

25. Operation Control: Front panel button/Remote control/USB Mouse

26. Operating System: Embedded Linux

27. Multiplex Function: Record/Playback/Network

28. Screen Division: 1/4/8/

29. Communication Port: RS485

30. Size: 335(W)×290(D)×58(H)

31. Power: DC 19V/3A
